In this episode we move away from verticals and start modelling loop antennas.

Using MMANA-GAL, we draw a horizontal delta loop and explore how it behaves compared to a vertical antenna.

Along the way we also look at how ground conditions affect antenna performance, and why antennas near salt water can perform dramatically better.

In this video we:

• Benchmark a vertical antenna at low take-off angles
• See how changing ground conductivity affects performance
• Draw a horizontal delta loop using the wire editor
• Place the feedpoint and model a 4:1 balun
• Use wire scaling to tune the antenna to the correct frequency
• Compare the far-field plots of a loop and a vertical

You’ll also see how loop antennas behave on multiple harmonics, making them useful multiband antennas.

In the next episode we’ll convert this into a vertically polarised delta loop and compare the radiation patterns again.

Software used

MMANA-GAL (Basic version)
Free download:
http://gal-ana.de/basicmm/en/

Model files used in this series

All MMANA-GAL antenna models used in these tutorials can be downloaded here:

📁 https://mega.nz/folder/EnoXlTQL#Iuq-TqnW7ZglzkJMEIk59w

This folder will be updated as new videos in the series are released.

Full Video Playlist

📺 https://www.youtube.com/playlist?list=PLcC64tNkZB7zl-6HKJ5ihuSH3-22IX6kq

If you want to follow the whole modelling series, subscribe so you don’t miss the next episode.

In this episode we take the ground mounted vertical from Part 3 and add elevated radials to see how the antenna behaves.

Using MMANA-GAL, we model a simple vertical and experiment with different radial configurations to see how they affect the far-field radiation pattern.

In this video we:

• Start with a basic ground mounted vertical
• Add two elevated radials
• Compare radiation patterns using the Compare function
• Add additional radials and experiment with geometry
• Raise the antenna and slope the radials downward
• Observe how the low-angle radiation changes

The goal here isn’t deep theory – it’s learning how to draw the antenna and observe what happens when you change the geometry.

You’ll also see how elevated radials can slightly improve low-angle radiation, which is important for DX performance.

In the next episode we’ll move on from verticals and start looking at loop antennas.

Software used

MMANA-GAL (Basic version)
Free download:
http://gal-ana.de/basicmm/en/

Model files used in this series

All MMANA-GAL antenna models used in these tutorials can be downloaded here:

📁 https://mega.nz/folder/EnoXlTQL#Iuq-TqnW7ZglzkJMEIk59w

This folder will be updated as new videos in the series are released.

Full Video Playlist

📺 https://www.youtube.com/playlist?list=PLcC64tNkZB7zl-6HKJ5ihuSH3-22IX6kq

If you want to follow the whole modelling series, subscribe so you don’t miss the next episode.
